complexType · extension xsd:double
Floating-point number
A number with an optional decimal point and an optional exponent. NaN (not a number), INF and -INF (infinity) are valid values.
| Value | Validity |
0.25 | valid |
-1.5e3 | valid, −1500 |
5 | valid |
NaN | valid |
INF | valid |
-INF | valid |
1,5 | invalid, decimal comma |
+INF | invalid, sign before INF |
nan | invalid, lower case |
| empty element | invalid |
Uncertainty (deprecated)
A value can be described as a random variable: @uncertaintyFunctionName names its probability distribution, and further attributes give the parameters of that distribution. Two distributions are defined:
| Distribution | Parameters |
GaussianNormalDistribution | @mu mean, @delta standard deviation |
ExponentialDistribution | @b mean, i.e. the inverse of the rate |
The attributes @a, @c, @v and @w belong to neither distribution.
| Name | Type | Constraints | Use | Default | Description |
|---|---|---|---|---|---|
@a | xsd:double | optional | Deprecated: not used by any distribution | ||
@b | xsd:double | optional | Deprecated: mean of the exponential distribution | ||
@c | xsd:double | optional | Deprecated: not used by any distribution | ||
@delta | xsd:double | optional | Deprecated: standard deviation of the normal distribution | ||
@externalDataDirectory | xsd:string | optional | Directory of the external file the element was read from, as URI | ||
@externalDataNodePath | xsd:string | optional | Path of the parent element in the merged dataset, at which the element was inserted from an external file | ||
@externalFileName | xsd:string | optional | Name of the external file the element was read from | ||
@mu | xsd:double | optional | Deprecated: mean of the normal distribution | ||
@uncertaintyFunctionName | uncertaintyFunctionType | 2 values | optional | Deprecated: probability distribution of the value (GaussianNormalDistribution or ExponentialDistribution) | |
@v | xsd:double | optional | Deprecated: not used by any distribution | ||
@w | xsd:double | optional | Deprecated: not used by any distribution |
cpacs/vehicles/aircraft/model/reference/areacpacs/vehicles/aircraft/model/reference/lengthcpacs/vehicles/aircraft/model/reference/point/xcpacs/vehicles/aircraft/model/reference/point/ycpacs/vehicles/aircraft/model/reference/point/zcpacs/vehicles/aircraft/model/configurationDefinitions/configurationDefinition/controlElements/controlElement/controlParametercpacs/vehicles/aircraft/model/configurationDefinitions/configurationDefinition/controlElements/controlElement/commandInputcpacs/vehicles/aircraft/model/configurationDefinitions/configurationDefinition/energyCarriers/storedFuels/storedFuel/storageConditions/temperaturecpacs/vehicles/aircraft/model/configurationDefinitions/configurationDefinition/energyCarriers/storedFuels/storedFuel/storageConditions/densitycpacs/vehicles/aircraft/model/configurationDefinitions/configurationDefinition/energyCarriers/storedFuels/storedFuel/storageConditions/pressurecpacs/vehicles/aircraft/model/configurationDefinitions/configurationDefinition/energyCarriers/storedFuels/storedFuel/storageComponents/storageComponent/storageConditions/temperaturecpacs/vehicles/aircraft/model/configurationDefinitions/configurationDefinition/energyCarriers/storedFuels/storedFuel/storageComponents/storageComponent/storageConditions/densitycpacs/vehicles/aircraft/model/configurationDefinitions/configurationDefinition/energyCarriers/storedFuels/storedFuel/storageComponents/storageComponent/storageConditions/pressurecpacs/vehicles/aircraft/model/ducts/duct/transformation/scaling/xcpacs/vehicles/aircraft/model/ducts/duct/transformation/scaling/ycpacs/vehicles/aircraft/model/ducts/duct/transformation/scaling/zcpacs/vehicles/aircraft/model/ducts/duct/transformation/rotation/xcpacs/vehicles/aircraft/model/ducts/duct/transformation/rotation/ycpacs/vehicles/aircraft/model/ducts/duct/transformation/rotation/zcpacs/vehicles/aircraft/model/ducts/duct/transformation/translation/xcpacs/vehicles/aircraft/model/ducts/duct/transformation/translation/ycpacs/vehicles/aircraft/model/ducts/duct/transformation/translation/zcpacs/vehicles/aircraft/model/ducts/duct/sections/section/transformation/scaling/xcpacs/vehicles/aircraft/model/ducts/duct/sections/section/transformation/scaling/ycpacs/vehicles/aircraft/model/ducts/duct/sections/section/transformation/scaling/z| Type | Name |
|---|---|
actuatorAttachmentType | etaControlSurface |
actuatorControlSurfaceAttachmentType | parentHeight |
actuatorControlSurfaceAttachmentType | parentXsi |
actuatorParentAttachmentType | parentHeight |
actuatorParentAttachmentType | parentXsi |
aeroCaseAeroDataType | angleOfAttack |
aeroCaseAeroDataType | angleOfSideslip |
aeroCaseSpecificationType | altitude |
aeroCaseSpecificationType | angleOfAttack |
aeroCaseSpecificationType | angleOfSideslip |
aeroCaseSpecificationType | machNumber |
aeroCaseSpecificationType | pStar |
aeroCaseSpecificationType | qStar |
aeroCaseSpecificationType | rStar |
aeroCaseSpecificationType | targetCl |
aeroPerformanceBoundaryConditionsType | deltaTemperature |
aircraftControlElementType | commandInput |
aircraftControlElementType | controlParameter |
airportType | elevation |
airportType | positionEast |
airportType | positionNorth |
alignmentCrossBeamType | offset1LocX |
alignmentCrossBeamType | offset2LocX |
alignmentCrossBeamType | rotationLocX |
alignmentCrossBeamType | translationLocY |
| and 647 more | |
