| leadingEdgeHollowType Complex Type |
Optional definition of the airfoil inner shape of leading edge devices (LED).
Namespace: Empty
Schema: Empty
Base Type
UsagesChildren| Name | Occurrences | Description |
|---|---|---|
 All | ||
 relHeightTE | Relative height of the most forward point of the LED's rear part, based on the airfoil height of the parent at this position. Optional. | |
| xsiTE | Relative chordwise position of the most forward point of the LED's rear part, based on the chord of the parent at this position. Optional. |
Attributes| Name | Type | Required | Description |
|---|---|---|---|
 externalDataDirectory |  string | Directory of the external data file | |
| externalDataNodePath | string | Path of the node inside the external data file | |
| externalFileName | string | Name of the external data file |
RemarksAll parameters are optional. For the definition of the parameters, please refer to the picture below. Parameters from the outer border default to the parameters of the inner border.
